該機型的運行狀態為“全自動運行”（無需人為操作設備的啟停），空氣進口、氮?dú)獬隹谠O(shè)有過濾調壓部件，內置冷凍干燥機及C、T、A三級過濾器、自動排水器。PC控制系統選用西門子。氮?dú)饧兌扔?9.9-99.999%氮?dú)夥治鰞x在線檢測，氮?dú)饧兌炔缓细褡詣优趴詹?bào)警，合格氮?dú)廨敵龊筮_(dá)到設定壓力自動停機。節省空壓機能耗達30%不等。制氮吸附塔交替運行，采用D型專用（專用閥門），帶有均壓功能，達到回收能耗，節能顯著。
適用于食品醫藥行業：面包、月餅、蛋黃派、法式面包、餅干、巧克力、雪米餅、藥品、葡萄酒、茶葉以及各種農副產品的充氮保鮮包裝
此款機型適合于對氮?dú)赓|(zhì)量要求比較高的中小食品企業進行充氮包裝。
Running state of the machine is "automatic operation" (that is, without the need for operating the start-stop of the equipment) . Air inlet and nitrogen outlet are equipped with pressure regulating components. the built-in refrigeration dryer and C, T, A three-stage filter and automatic drainage device. Nitrogen purity is monitored by analyzer on-line, by 99.9-99.999% unit. Automatic emptying and alarm are set if the purity of nitrogen is unqualified, and the system will automatically stop when it reaches the set pressure after qualified nitrogen output, thus, saving power consumption of the air compressor by up to 30%. Nitrogen adsorption towers operating alternately, adopts Type D dedicated (special valve) and have pressure equalizing function to achieve the effect of recycling energy consumption and saving energy.
Applicable to the food and pharmaceutical industry: the nitrogen-filled preservation and packaging of bread, moon cake, yolk pie, French bread, biscuits. chocolate, snow cake, pharmaceuticals, wine, tea and various agricultural and sideline products .
This machine is suitable for small and medium food enterprises with demand of high-quality nitrogen-filled packaging.
適用于食品醫藥行業：面包、月餅、蛋黃派、法式面包、餅干、巧克力、雪米餅、藥品、葡萄酒、茶葉以及各種農副產品的充氮保鮮包裝。
此款機型適合個體食品企業進行充氮包裝。建議使用節能系列食品保鮮制氮機。
Applicable to the food and pharmaceutical industry : the nitrogen-filled preservation and packaging of bread, moon cake, yolk pie, French bread, biscuits. chocolate. snow cake, pharmaceuticals, wine, tea and various agricultural and sideline products.
This machine is suitable for individual food companies in nitrogen-filled packaging. It is recommended to use energy-saving series of nitrogen making machine for food preservation.
| 型號規格 Model |
氮?dú)猱a(chǎn)量 Nitrogen production Nm3/h |
功率 Power W |
氮?dú)饧兌?br />
Nitrogrn purity % |
氣源壓力 Gas pressure Mpa |
產氮壓力 Pressure of production nitrogen Mpa |
外形尺寸 Appearance size L×W×H(mm) |
|
| SC-8D | 碳鋼 Carbon steel |
8 | 300 | ≥99.9-99.999 | 0.8-1.0 | 0.1-0.65 | 1080×750×1500 |
| 不銹鋼 Stainless steel |
|||||||
| 注：可供三臺枕式包裝機充氮?dú)猓x配空壓機排量：0.4Nm3/min-10 Ps: It enables 3 pillow packaging machine to fill nitrogen and the matched air compressor capacity is 0.4 Nm3/min-10. |
|||||||
| SC-10D | 碳鋼 Carbon steel |
10 | 300 | ≥99.9-99.999 | 0.8-1.0 | 0.1-0.65 | 1080×750×1500 |
| 不銹鋼 Stainless steel |
|||||||
| 注：可供四臺枕式包裝機充氮?dú)饣蚨_大立式包裝機充氮?dú)?，選配空壓機排量：0.6Nm3/min-10 Ps: It enables 4 pillow packaging machines or 2 big vertical packaging machine to fill nitrogen and the matched air compressor capacity is 0.6Nm3/min-10 |
|||||||
配套小型氮?dú)鈨蓿?0L、高壓管3m、5m（贈品）
|
||||
|
||||
